Wireless Alfa AWUS036H Driver

Wednesday, February 24, 2010
Posted by BAT32
Bookmark Digg Bookmark Del.icio.us Bookmark Facebook Bookmark Reddit Bookmark StumbleUpon Bookmark Yahoo Bookmark Google Bookmark Technorati Bookmark Twitter

Feature:

  • Connects at a full 54Mbps via USB 2.0, up to 8 times faster than a USB 1.1 adapter
  • High gain upgradeable
  • Compact size for greater flexibility
  • Also compatible with USB 1.1 desktop and notebook computers
  • Plug-and-Play Compatible with windows 98SE, 2000, Millennium, XP and Linux
  • High security 64/128/256bit WEP Encryption, TKIP, WPA, 802.11
Specification:

  • Model: AWUS036H
  • Standards: Wireless IEEE 802.11 b/g USB 2.0 Standard
  • Data Rate: 802.11b Up To 11 Mbps - 802.11g 54 Mbps
  • OS Support: Windows 98SE, Windows ME, Windows 2000, Windows XP, Vista, 7, Linux 2.6, Mac 10.4
  • Interface: USB 2.0 Mini USB
  • Antenna Type: 1 x 2.4 GHz SMA Connector
  • Chipset: Realtek 8187L
  • One LED: Power/Status Wireless Act
  • Frequency Range: 2412~2462 MHz (NA), 2412~2472 MHz (EU), 2412~2484 MHz (Japan)
  • Channel: 1~11 Channels (North America), 1~13 Channels (General Europe), 1~14 Channels (Japan)
  • Emission Type: DSSS/OFDM
  • Output Power: 24dBm (OFDM), 30dBm (CCK)
  • Sensitivity for 802.11b: 1, 2 Mbps (BPSK, QPSK): - 96dBm
    11 Mbps (CCK): -91dBm
    (Typically @PER < 8% packet size 1024 and
    @25ºC + 5ºC)
  • Sensitivity for 802.11g: 54Mpbs (64QAM): -76dbm
    48Mbps (64QAM): -71dbm
    36Mpbs (16QAM): -78dbm
    24Mbps (16QAM): -80dbm
    18Mbps (QPSK): -81dbm
    12Mpbs (QPSK): -82dbm
    9Mbps (BPSK): -85dbm
    6Mbps (BPSK): -91dbm
    (typically @PER < 10% packet size 1024 and @25ºC + 5ºC)
  • Frequency Stability: within +25 ppm
  • Data Modulation Type: BPSK,QPSK, CCK and OFDM
  • Power: Voltage: 5V+5%
  • Security: WEP 64/128
    802.1X support
    Wi-Fi Protected Access (WPA)
    WPA-PSK
    WPA II
  • Operating Temp: 0°C ~ +50°C
  • Storage: -10°C ~ +65°C
  • Humidity: 5%~98% non-condensing
  • Dimension: 8.5*2.2*6.3cm
  • Weight: 38.5g
Download Drivers

Installation Guide for Windows Vista



Installation Guide for Windows 7
